All Deprecated Features & APIs
All deprecated APIs are considered unsupported as of the version they are deprecated. They may be removed at any time with no further notice.
18.4
PDF Rasterizer
[Alternative] Use the SetReaderOptions() and GetReaderOptions() functions instead.
- GetConvertMode()
- SetConvertMode()
- SetPassword()
- SetResolution()
Deprecate the enum value CM_RENDERALLWITHANNOTATION from Dynamsoft.DWT.EnumDWT_ConvertMode
.
Viewer
This API has been deprecated as of release 18.4. Please use the
updateSelectionBoxStyle()
function.
- selectedAreaBorderColor
18.2
Global
- Dynamsoft.DWT.GetWebTwainEx()
18.0
Dynamic Web TWAIN
[Alternative] Use Dynamsoft.DWT.ProductKey instead.
- Dynamsoft.DWT.licenseServer
- Dynamsoft.DWT.sessionPassword
- Dynamsoft.DWT.organizationID
- Dynamsoft.DWT.handshakeCode
Util
- Deprecated Method: DWTObject.SetProductKeyAsync
- Deprecated Property: DWTObject.ProductKey
Scan
- Deprecated Method: DWTObject.GetDeviceType
17.3
Dynamic Web TWAIN
- Deleted property: Dynamsoft.DWT.UseDefaultInstallUI
Viewer
[Alternative] Use updateCheckboxStyle and updatePageNumberStyle instead.
- Viewer.showPageNumber
- Viewer.showCheckbox
- thumbnailViewer.showCheckbox
- thumbnailViewer.showPageNumber
Camera Add-on
[Alternative] Use scanDocument instead.
- Camera.showVideo()
17.0
Viewer
- New APIs in v17.0 replace old APIs in v16.2-, all old APIs are deprecated.
v17.0 | v16.2- |
---|---|
Viewer.autoChangeIndex |
Viewer.topPageChanged() |
- The following APIs are new in v17.0
-
RemoveTag
-
GetTagList
DWT.licenseServer
DWT.handshakeCode
DWT.sessionPassword
DWT.licenseException
-
16.2
- Internet Explorer 8 is no longer supported.
Camera Add-on
- New APIs in v16.2 replace old APIs in v16.1-, all old APIs are deleted.
v16.2 | v16.1- |
---|---|
Addon.Camera.showVideo() |
Viewer.showVideo() |
Addon.Camera.closeVideo() |
Viewer.closeVideo() |
Addon.Camera.off() |
Viewer.off() |
Addon.Camera.on("video-closed") |
Viewer.on("video-closed") |
Addon.Camera.on("video-error") |
Viewer.on("video-error") |
Viewer
- New APIs in v16.2 replace old APIs in v16.1-, all old APIs are deprecated.
v16.2 | v16.1- |
---|---|
Viewer.background |
BackgroundColor |
Viewer.bind() , Viewer.show() , Viewer.hide() |
BindViewer() |
Viewer.cursor |
MouseShape |
Viewer.fitWindow() |
FitWindowType , IfFitWindow |
Viewer.height |
Height |
Viewer.ifAutoScroll |
IfAutoScroll |
Viewer.on("click", callback) |
RegisterEvent("OnMouseClick", callback) |
Viewer.on("contextmenu", callback) |
RegisterEvent("OnMouseRightClick", callback) |
Viewer.on("dblclick", callback) |
RegisterEvent("OnMouseDoubleClick", callback) |
Viewer.on("mousemove", callback) |
RegisterEvent("OnMouseMove", callback) |
Viewer.on("pageAreaSelected", callback) |
RegisterEvent("OnImageAreaSelected", callback) |
Viewer.on("pageAreaUnselected", callback) |
RegisterEvent("OnImageAreaDeSelected", callback) |
Viewer.pageMargin |
ImageMargin |
Viewer.selectedPageBorder |
SelectionImageBorderColor |
Viewer.selectionRectAspectRatio |
SelectionRectAspectRatio |
Viewer.setSelectedAreas() |
SetSelectedImageArea() |
Viewer.showPageNumber |
ShowPageNumber |
Viewer.unbind() |
UnbindView() |
Viewer.width |
Width |
Viewer.zoom |
Zoom |
ViewerEvent.imageX |
MouseX |
ViewerEvent.imageY |
MouseY |
NOTE
ViewerEvent.imageX
andViewerEvent.imageY
are only available as the first argument in callback functions for the mouse events “click”, “dblclick”, “contextMenu” and “mousemove”.
- The following APIs are new in v16.2
-
Viewer.acceptDrop
-
Viewer.allowSlide
-
Viewer.clearSelectedAreas()
-
Viewer.createThumbnailViewer()
-
Viewer.border
-
Viewer.first()
-
Viewer.getUISettings()
-
Viewer.gotoPage()
-
Viewer.idPostfix
-
Viewer.innerBorder
-
Viewer.last()
-
Viewer.next()
-
Viewer.on("pageRendered", callback)
-
Viewer.on("resize", callback)
-
Viewer.previous()
-
Viewer.render()
-
Viewer.resetUISettings()
-
Viewer.selectedAreaBorderColor
-
Viewer.selectedPageBackground
-
Viewer.singlePageMode
-
-
The following APIs in v16.2 are improved based on old APIs in v16.1-.
-
It also accepts the values “-1, -1” which is equivalent to setting
Viewer.singlePageMode
totrue
.
-
-
The following APIs are also deprecated in v16.2
-
SetViewMode()
Use Viewer.setViewMode() instead.
-
-
The following APIs from v16.1- are removed
Viewer.bOnlyShowThumbnailsView
Viewer.cursorOverThumbnailsView
Viewer.bindCustomElement()
Viewer.showCustomElement()
Viewer.hideCustomElement()
Viewer.toggleCustomElement()
Viewer.setSelectedImageArea()
Viewer.zoomIn()
Viewer.zoomOut()
- The following APIs in v16.1- are implemented differently in v16.2
BindViewer()
with two parametersUpdateViewer()
The two methods above were used to set the size of the viewer or to show the thumbnail viewer. In v16, 2, different APIs are used as shown below:
/* Set the size of the viewer */
DWTObject.Viewer.height = 800;
DWTObject.Viewer.width = 600;
/* Create a thumbnail viewer, note that this viewer can be hidden or disposed */
var objThumbnailViewer = DWTObject.Viewer.createThumbnailViewer(thumbnailViewerSettings);
objThumbnailViewer.show();
//objThumbnailViewer.hide();
//objThumbnailViewer.dispose();
/* updateViewMode() is used to change only the view mode of the thumbnail viewer */
objThumbnailViewer.updateViewMode(viewMode: ViewMode);
/* The following two are used to hook or unhook events to the thumbnail viewer */
objThumbnailViewer.on()
objThumbnailViewer.off()
ShowImageEditor()
While this method still works, it’s deprecated and the alternative is shown in the code below
/* The image editor is now created on the fly and can be hidden or disposed */
var objImageEditor = DWTObject.Viewer.createImageEditor(editorSettings);
objImageEditor.show();
objImageEditor.hide();
objImageEditor.dispose();
Viewer.bindCustomElement()
Viewer.showCustomElement()
Viewer.hideCustomElement()
Viewer.toggleCustomElement()
As already mentioned, these four methods are removed and the alternative implementation is shown in the code below
var objCustomElement = DWTObject.Viewer.createCustomElement(document.getElementById("divCustomElement"));
objCustomElement.show();
objCustomElement.hide();
objCustomElement.dispose();
16.1.1
TWAIN Capability Negotiation
[Alternative] Use getCapabilities() and setCapabilities() instead.
- CapGet()
- CapGetHelp()
- CapGetCurrent()
- CapGetDefault()
- CapGetFrameBottom()
- CapGetFrameLeft()
- CapGetFrameRight()
- CapGetFrameTop()
- CapGetLabel()
- CapGetLabels()
- CapSet()
- CapReset()
- CapSetFrame()
- CapIfSupported()
- GetCapItems()
- GetCapItemsString()
- SetCapItems()
- SetCapItemsString()
- Capability
- CapNumItems
- CapMaxValue
- CapMinValue
- CapCurrentValue
- CapCurrentIndex
- CapDefaultValue
- CapDefaultIndex
- CapType
- CapValueType
- CapStepSize
- CapValue
- CapValueString
Buffer Management
[Alternative] Use SelectedImagesIndices, SelectAllImages() and SelectImages() instead.
- GetSelectedImageIndex()
- SetSelectedImageIndex
- SelectedImagesCount
Image Editing
- AddText()
- CreateTextFont()
- OverlayRectangle()
Input and Output
[Alternative] Use new methods like ConvertToBase64(), PDF.Write.Setup()
- SaveSelectedImagesToBase64Binary()
- SetCookie()
- IfOpenImageWithGDIPlus
- PDFAuthor
- PDFCompressionType
- PDFCreationDate
- PDFCreator
- PDFKeywords
- PDFModifiedDate
- PDFProducer
- PDFSubject
- PDFTitle
- PDFVersion
- MaxInternetTransferThreads
Viewer
[Alternative] Use methods like Viewer.setViewMode(), Viewer.setViewMode()
- SetViewMode()
- SetSelectedImageArea()
